Softr

Build custom apps and tools with Softr, on top of your Xano database — no code required. Display data in interactive layouts, and create stunning UI with drag-and-drop elements.

It’s never been easier to build powerful, scalable apps.

Integrating Xano with Softr

When you connect your Xano database to Softr, you unlock a whole new set of possibilities — no coding or technical background required.

Xano’s database gives you the power to source and manage large datasets with the simplicity of a spreadsheet. You can then use that data to build out dashboards, portals, and internal tools in Softr. Create fast with drag-and-drop elements, all while leveraging total design freedom.

In this step-by-step guide, we show you how to connect Xano to Softr — and start building in minutes.

Pre-requisites

Before we start, make sure you have the following:

• Xano account with a Starter or Pro plan.
• Xano Database Connector: This feature is an add-on available for our Launch and Scale plans. It enables you to connect your Xano database with external apps and services, like Softr. Learn more.
• Softr account with any plan.

Step 1: Configure within Xano

In order for Softr to access your Xano instance, you first need to configure the Database Connector.

1. From your Xano dashboard, click on the settings icon next to the instance that you want to connect to Softr.
2. Select Database Connector from the menu on the right.
3. Click the GET buttons next to “Database Public IP” and “Database Credentials”.
4. Save your database credentials in a secure location. They’re hidden for security purposes, but you can reveal them when you check the box next to Show credentials.
5. Click on the Settings tab.
6. Click on the +Add button.
7. Paste in Softr’s three IP addresses, and then click the Save button. Softr’s IP addresses are:
   • 3.120.79.212
   • 3.123.159.186
   • 52.58.246.121

Step 2: Connect within Softr

After you have everything set up within Xano, you can connect your database within Softr. You can edit this connection in your Softr dashboard at any time.

1. From your Softr dashboard, select Data sources from the menu on the left.
2. Click the Connect data source button in the upper-right-hand corner.
3. Select Xano.
4. Fill in the Name field with whatever name you want. Ensure the Port field is “5432”.
5. In the remaining fields, copy and paste your database credentials from Xano. Before you paste in the credentials, make sure that they’re unhidden.
6. You have both full-access and read-access credentials from the Database Connector. Softr recommends that you always input the full-access credentials, so you don’t need to re-authenticate if you enhance your app’s capabilities.
7. The field mappings are as follows:
   • Host: corresponds to “host” from the credentials.
   • Database: corresponds to “database”.
   • User: corresponds to “user”.
   • Password: corresponds to “pass”.
8. Click the Connect button in the lower-right-hand corner.

---

Great work! You’ve successfully connected your Xano database with Softr.

With this combination of Xano and Softr, it’s never been easier to create powerful, scalable apps. Happy building!
